Megaflo Eco 70 Litre Indirect Unvented Hot Water Cylinder

Megaflo 70 Litre Eco Direct Unvented Hot Water Cylinder

Megaflo are the market leaders in Hot Water Cylinders. The internal expansion system keeps external pipework to a minimum, removing the need for a separate expansion vessel. UK designed, engineered and manufactured, to exacting detail and from Duplex stainless steel. 100% pressure tested to 1.6MPa (16 bar) The unit is supplied complete with all the necessary safety and control devices needed to allow connection to the cold water mains. All these components are preset

Package includes:

• Cylinder incorporating factory fitted immersion heater(s) and thermal controls
• factory fitted temperature and pressure relief valve
• Instructions (Inc benchmark commissioning checklist & service record)
• Cold water control pack
• Combination valve (Inc pressure reducing valve, pressure relief valve, check valve and isolating valve)
• Tundish
• 2 port zones valves (indirect only)
• Wiring centre (indirect only)
• T&P relief valve insulation set
• Drain valve

Megaflo Eco Indirect Unvented Hot Water Cylinder Specification

• Internal floating baffle expansion system
• 60 mm of CFC / HCFC-free injected foam for the best possible heat retention and energy efficiency
• High performance ‘coil-in-coil’ heat exchanger in indirect models for exceptionally fast recovery times
• Unique ‘L’ shaped immersion heater maximises the volume of hot water available when heated electrically
• Titanium electric heating elements on direct models for extra long-life



Megaflo Eco 70 Litre Indirect Specifications

Capacity (Litres)	70
Height (mm)	802
Width (mm)	579
Weight – Empty (kg)	25
Weight – Full (kg)	125
Coil Rating (kW)	15.4
ErP rating	B



Delivery

All our Cylinders are for delivery by customer offload. This entails the customer to acquire the right manpower and/or machinery to help unload the tank/s from the delivery vehicle.

If you require assistance with offloading, we may be able to offer a tail lift (lowers the tank to the ground) or HIAB (lorry with a mounted crane to winch the tank off the delivery vehicle). Please contact us if this is required for delivery.



• Product Code: PFW
• Customer Offloading: Customer Offloading
• Delivery: Free Delivery
